USB流量知识点小结
1640 浏览 | 2020-04-08 | 阅读时间: 约 3 分钟 | 分类: MISC | 标签: Misc,知识点
请注意,本文编写于 530 天前,最后修改于 517 天前,其中某些信息可能已经过时。

USB接口是目前最为通用的外设接口之一,通过监听该接口的流量,可以得到很多有意思的东西,例如键盘击键,鼠标移动与点击,存储设备的明文传输通信、USB无线网卡网络传输内容等。

前言

USB流量的捕获可以使用wireshark或usbpcap来进行,在ctf中通常会给出已经捕获好的流量包,而我们需要做的便是从流量包中还原捕获的数据。USB流量分为两大类:键盘流量和鼠标流量。下面会分别进行解析。

键盘流量

附件链接:https://pan.baidu.com/s/1aJ_EDTqpUJht7Mpybnw5zQ

提取码:zuqw

注:以下内容以附件中的题为例

USB协议的数据部分在Leftover Capture Data域中,用wireshark打开流量包

在蓝色部分可以看到这个区域,右键→应用为列,即可在上面显示出来这一列

键盘流量的数据长度为8个字节,其中有关击键的信息在第三字节(十六进制表示)

详细的击键信息对照表可参考:https://max.book118.com/html/2017/0407/99227972.shtm

tshark命令可以提取对应的Leftover Capture Data域中数据:

tshark -r usb.pcap -T fields -e usb.capdata > usbdata.txt

如果提取出来的数据有空行,可以将命令改为如下形式:

tshark -r usb.pcapng -T fields -e usb.capdata | sed '/^\s*$/d' > usbdata.txt

提取出来的数据

提取出来的数据可能会带冒号,也可能不带(有可能和wireshark的版本相关),但是一般的脚本都会按照有冒号的数据来识别,有冒号时提取数据的[6:8],无冒号时数据在[4:6],可以用脚本来加上冒号

f=open('usbdata.txt','r')
fi=open('out.txt','w')
while 1:
    a=f.readline().strip()
    if a:
        if len(a)==16: # 鼠标流量的话len改为8
            out=''
            for i in range(0,len(a),2):
                if i+2 != len(a):
                    out+=a[i]+a[i+1]+":"
                else:
                    out+=a[i]+a[i+1]
            fi.write(out)
            fi.write('\n')
    else:
        break

fi.close()

得到这样的数据,此时对应的第三字节,也就是[6:8]就代表了击键信息

提取出键盘流量后需要用脚本还原数据对应的信息,附上两个还原信息较为完整的脚本(python2)

normalKeys = {
    "04":"a", "05":"b", "06":"c", "07":"d", "08":"e",
    "09":"f", "0a":"g", "0b":"h", "0c":"i", "0d":"j",
     "0e":"k", "0f":"l", "10":"m", "11":"n", "12":"o",
      "13":"p", "14":"q", "15":"r", "16":"s", "17":"t",
       "18":"u", "19":"v", "1a":"w", "1b":"x", "1c":"y",
        "1d":"z","1e":"1", "1f":"2", "20":"3", "21":"4",
         "22":"5", "23":"6","24":"7","25":"8","26":"9",
         "27":"0","28":"<RET>","29":"<ESC>","2a":"<DEL>", "2b":"\t",
         "2c":"<SPACE>","2d":"-","2e":"=","2f":"[","30":"]","31":"\\",
         "32":"<NON>","33":";","34":"'","35":"<GA>","36":",","37":".",
         "38":"/","39":"<CAP>","3a":"<F1>","3b":"<F2>", "3c":"<F3>","3d":"<F4>",
         "3e":"<F5>","3f":"<F6>","40":"<F7>","41":"<F8>","42":"<F9>","43":"<F10>",
         "44":"<F11>","45":"<F12>"}
shiftKeys = {
    "04":"A", "05":"B", "06":"C", "07":"D", "08":"E",
     "09":"F", "0a":"G", "0b":"H", "0c":"I", "0d":"J",
      "0e":"K", "0f":"L", "10":"M", "11":"N", "12":"O",
       "13":"P", "14":"Q", "15":"R", "16":"S", "17":"T",
        "18":"U", "19":"V", "1a":"W", "1b":"X", "1c":"Y",
         "1d":"Z","1e":"!", "1f":"@", "20":"#", "21":"$",
          "22":"%", "23":"^","24":"&","25":"*","26":"(","27":")",
          "28":"<RET>","29":"<ESC>","2a":"<DEL>", "2b":"\t","2c":"<SPACE>",
          "2d":"_","2e":"+","2f":"{","30":"}","31":"|","32":"<NON>","33":"\"",
          "34":":","35":"<GA>","36":"<","37":">","38":"?","39":"<CAP>","3a":"<F1>",
          "3b":"<F2>", "3c":"<F3>","3d":"<F4>","3e":"<F5>","3f":"<F6>","40":"<F7>",
          "41":"<F8>","42":"<F9>","43":"<F10>","44":"<F11>","45":"<F12>"}
output = []
keys = open('out.txt')
for line in keys:
    try:
        if line[0]!='0' or (line[1]!='0' and line[1]!='2') or line[3]!='0' or line[4]!='0' or line[9]!='0' or line[10]!='0' or line[12]!='0' or line[13]!='0' or line[15]!='0' or line[16]!='0' or line[18]!='0' or line[19]!='0' or line[21]!='0' or line[22]!='0' or line[6:8]=="00":
             continue
        if line[6:8] in normalKeys.keys():
            output += [[normalKeys[line[6:8]]],[shiftKeys[line[6:8]]]][line[1]=='2']
        else:
            output += ['[unknown]']
    except:
        pass

keys.close()

flag=0
print("".join(output))
for i in range(len(output)):
    try:
        a=output.index('<DEL>')
        del output[a]
        del output[a-1]
    except:
        pass

for i in range(len(output)):
    try:
        if output[i]=="<CAP>":
            flag+=1
            output.pop(i)
            if flag==2:
                flag=0
        if flag!=0:
            output[i]=output[i].upper()
    except:
        pass

print ('output :' + "".join(output))
mappings = { 0x04:"A",  0x05:"B",  0x06:"C", 0x07:"D", 0x08:"E", 0x09:"F", 0x0A:"G",  0x0B:"H", 0x0C:"I",  0x0D:"J", 0x0E:"K", 0x0F:"L", 0x10:"M", 0x11:"N",0x12:"O",  0x13:"P", 0x14:"Q", 0x15:"R", 0x16:"S", 0x17:"T", 0x18:"U",0x19:"V", 0x1A:"W", 0x1B:"X", 0x1C:"Y", 0x1D:"Z", 0x1E:"1", 0x1F:"2", 0x20:"3", 0x21:"4", 0x22:"5",  0x23:"6", 0x24:"7", 0x25:"8", 0x26:"9", 0x27:"0", 0x28:"\n", 0x2a:"[DEL]",  0X2B:"    ", 0x2C:" ",  0x2D:"-", 0x2E:"=", 0x2F:"[",  0x30:"]",  0x31:"\\", 0x32:"~", 0x33:";",  0x34:"'", 0x36:",",  0x37:"." }

nums = []
keys = open('out.txt')
for line in keys:
    if line[0]!='0' or line[1]!='0' or line[3]!='0' or line[4]!='0' or line[9]!='0' or line[10]!='0' or line[12]!='0' or line[13]!='0' or line[15]!='0' or line[16]!='0' or line[18]!='0' or line[19]!='0' or line[21]!='0' or line[22]!='0':
         continue
    nums.append(int(line[6:8],16))

keys.close()

output = ""
for n in nums:
    if n == 0 :
        continue
    if n in mappings:
        output += mappings[n]
    else:
        output += '[unknown]'

print 'output :\n' + output

此题我用了第二个脚本,还原得到以下信息

将其中[DEL]对应的字符删去,得到

HELLO , I AM WRITING SOMETHING IMPORTANT .
BUT I DO NOT USE PINYIN
I AM OLD .

DDPEIYUJ,Q S GAVCLWBMPYG RUG STK B .
I FPI J ET K YYGY R GAAA LWBMR .
WQ SK C RCN GHDMP QKD YTD R RUUJ WT O PYG RUG STK RJUQ H FCU

Q YI J PYG RUG STK KWKW


OVER
ENJOY MY MISC .

最后再用五笔输入下中间的看似乱码的字符串,就可以得到flag

ps:重要的不是五笔,而是借这道题来讲述有关键盘流量的提取和解密,不要过于纠结五笔……

鼠标流量

附件链接:https://pan.baidu.com/s/1lIDKVmnNkqhv4h3JNsx8Mg

提取码:a1tn

鼠标流量的提取方式和上述键盘流量的方式相同,但不同的是鼠标流量的数据长度为4字节

以附件中的流量包为例

删去提取出来的数据中长度不正确的数据(没有冒号可用上面提到过的脚本加上),得到

在鼠标流量数据中,第一字节代表按键,当取0x00时代表没有按键,取0x01时代表按左键,取0x02时代表按右键。第二个字节可以看成是一个signed byte类型,当这个值为正时,代表鼠标水平右移多少像素,为负时,代表水平左移多少像素。第三个字节与第二字节类似,代表垂直上下移动的偏移。(具体可见下面的代码)

nums = []
keys = open('out.txt','r')
f = open('xy.txt','w')
posx = 0
posy = 0
for line in keys:
    if len(line) != 12 :
        continue
    x = int(line[3:5],16)
    y = int(line[6:8],16)
    if x > 127 :
        x -= 256
    if y > 127 :
        y -= 256
    posx += x
    posy += y
    btn_flag = int(line[0:2],16)  # 1 for left , 2 for right , 0 for nothing
    if btn_flag == 1 : # 1 代表左键
        f.write(str(posx))
        f.write(' ')
        f.write(str(posy))
        f.write('\n')

f.close()

本题的flag信息藏在右键中,当脚本中btn_flag取2时可以得到一系列坐标

熟悉的坐标形式,用gnuplot转化成图像即可

看起来是颠倒的,导出后convert翻转一下即可

得到flag:XNUCA{USBPCAPGETEVERYTHING}
